Specifications：

• Throat Diameter:      1in(25mm)
• Mounting Type:        Screw on 1-3/8”
• Nominal Impedance:  8 ohm
• Power Capacity:       30Watts RMS (pink noise signal -12db/OCT)
• Sensitivity(1W/1M):  107dB(mounted on JC H-613 horn)
• Frequency Range:    1.5-20KHz
• Diaphragm Material:  PPS
• Voice Coil Diameter: 1.5in(38mm)
• Voice Coil Material:   Round or Ribbon Aluminium Wire
• Flux Density:           1.8T
• Magnet Material:     Neodymiun N-38H

Packing Details:

• Overall Diameter: ф64mm(2.52in)
• Depth:               48.5mm(1.9in)
• Net Weight:        2.9kg
• Pcs/CTN:            12 Pcs
