| Sensitivity: | 1W/1m118 dB |
| Frequency range: | 200 – 9000 Hz |
| Horn size: | 640×330×570mm |
| Recommended crossover: | 300 Hz |
| min.impendancemodulus: | 8.3 Ohm at 5 kHz |
| Voice coil diameter: | 3.5” (90 mm) |
| Magnet: | 180×95×20mm |
| Flux density (Tesla): | 1.8T |
| Voice Coil Material: | Aluminium |
| Voice coil former: | Kapton |
| Diaphragm material: | Polyester |
| Throat diameter: | 2” (50.8 mm) |
| Nominal impedance: | 8Ohm |
| Power capacity (AES): | 150 W RMS above 400 Hz |
| Depth: | 98mm |
