| Magnetic tile circuit invention patent | |
| NO:201410167713.7 | |
| Specifications： | |
| Throat Diameter: | 3.0 in(75.5mm) |
| Mounting Type: | Bolt-on |
| Sensitivity (1W/1M): | 108dB |
| Power Capacity: | 150 Watts RMS |
| Frequency Range: | 300Hz-10000Hz |
| Diaphragm Material: | 4/8/16 Ohm |
| Diaphragm Material: | Titanium |
| Voice Coil Diameter: | 99.2 mm (3.90 in) |
| Voice Coil Material: | Round or Ribbon Aluminium Wire |
| Flux Density: | 2.10T |
| Magnet: | Neodymium |
| Packing Details: | |
| Overall Diameter x Depth: | Ф 150mm x 108mm |
| Net Weight: | 6.42kg |
| Pcs/CTN: | 2pcs |
| Carton Size: | 43×23.5×10.6cm |
