Specifications：

• Throat Diameter:     1in(25mm)

• Mounting Type:       Screw on 1-3/8”

• Nominal Impedance: 8 ohm

• Power Capacity:      30Watts RMS (pink noise signal -12db/OCT)

• Sensitivity(1W/1M): 107dB(mounted on JC H-613 horn)

• Frequency Range:   1.5-20KHz

• Diaphragm Material: PPS

• Voice Coil Diameter:1.5in(38mm)

• Voice Coil Material:  Round or Ribbon Aluminium Wire

• Flux Density:          1.7T

• Magnet Material:    Neodymiun N-38SH

Packing Details:

• Overall Diameter: ф64mm(2.52in)

• Depth:               52mm(2.0in)

• Net Weight:       0.45kgs

• Pcs/CTN:            12 Pcs
